Technical Specifications
Frontside
13 mm water resistant HPL-Panels with coarse matt surface on both sides. All visible edges milled and bevelled. An aluminium cover rail, 37 x 29 mm, which runs over the entire front, guarantees high stability. Wall connections with square aluminium-U-profiles 17 x 30 mm.
Doors
Same material as front walls, self closing. All visible edges milled and bevelled in 1 mm radius and all corners are rounded off in 3 mm radius. Square aluminium door stop profile 37x 25,6 mm.Rubber seal on lock side for silent closing.
WC cubicles
Same material as front walls. All visible edges milled and bevelled. Wall and front connections with square aluminium-U-profiles 17 x 30 mm.
Panel material
13 mm thick HPL solid core panels, which have a special surface finish to make them highly scratch-resistant, low-wear and abrasion-resistant. The solid-core material means that the edges are not finished with an edge band, but are milled directly from the panel material. This system is totally waterproof and a benchmark for stability and functionality.
- Made of 13 mm HPL plate
- With square aluminium profiles
- Suitable for the highest demands in wet areas
